RN8006 ECG Machine Full digital filter, HighResolution Thermal Printer perfect ECG wave, The RN8006 ECG Machine is designed with high-quality components and advanced technologies. It undergoes strict quality control during the production process to ensure stable performance and high reliability. Whether in a hospital ward or a home healthcare environment, it can provide accurate and continuous monitoring data.
Product advantages
Our advantages
The first choice for a physical examination center is a full digital filter, a high-resolution thermal printer, and a perfect ECG wave. The RN8006 ECG Machine is designed with high-quality components and advanced technologies. It undergoes strict quality control during the production process to ensure stable performance and high reliability. It can provide accurate and continuous monitoring data in a hospital ward or a home healthcare environment.
Features:
- Complete digital design, High Resolution Thermal Printer
- Simultaneously 12 Leads Acquisition, Synchronous Record Details of 6 ECG Waveforms automatically waveform analysis report out fully.
- Full digital filter, High Resolution Thermal Printer, perfect ECG wave
- Both auto and manual mode are available.
- Match high-resolution color screen and user-friendly menu, touch-screen for option.
- AC.EMG interference avoiding baseline drift,
- AC/DC power supply built-in rechargeable Lion battery, support Uninterrupted Working Up to 3Hours without AC power
- Slight key, support touch-screen input, single button operation
- Standard output/input interface, flexible output print pattern: three channel, three channel + any rhythm lead
- Support continuous 60 seconds of waveform in selected lead, automatically analyze and revive the waveform, useful to diagnose arrhythmia.
- Support lead-fail detector
- Data storage & transmission
- SD card, convenient for data exchange
- USB printer interface, support character, symbols, waveform output
- Support communicate with PC via RS232 and Ethernet
Technology specifications
| Index |
Parameters |
Index |
Parameters |
| Acquisition mode |
Simultaneously 12 Leads Acquisition |
Rhythm lead |
optional |
| Input |
Isolated input, defibrillation-Proof test, Pace-maker pulse detect & suppression |
Operation mode |
auto or manual mode |
| Input impedance |
≥50MΩ(10Hz) |
Frequency response |
0.05-150Hz(-3dB) |
| Input circuit current |
≤50nA |
Record speed |
6.25,12.5, 25, 50mm/s |
| Gain |
2.5, 5, 10, 20mm/mV |
Record paper |
110mm*20m stock form or fanfold |
| Filter |
AC Filter50/60Hz(-20dB)
EMG Filter35/45Hz(-3dB) |
Sampling rate |
1000Hz, Simultaneously 12 Leads Acquisition |
| Electrode offset potential |
±400mV |
A/D Resolution |
24 bit |
| CMRRI |
≥100dB |
Display |
4.3” high-resolution color screen,
Multi-language support,
colored waveform display |
| Calibration Signal |
1mV±2% |
Analyse function |
Chinese/English analysis report |
| Time constant |
3.2s(0,+20% ) |
External input |
10mm/V±5%; ≥100KΩ |
| Noise |
≤15μVp-P |
ECG output |
1V/mV±5%; ≤100Ω |
| Baseline control |
Auto |
Safety class |
Class I /CF |
| Record system |
High Resolution Thermal Printer,
Multi-language display and print |
Capability of patients’ information |
More than 100 patients records |
Usage scenario
Hospital Wards
RN8006 ECG Machine monitors heart condition: During surgery, intensive care, and emergencies, the ECG machine is used to monitor the patient's heart activity in real time so that abnormalities can be detected in time. Evaluate the effect of heart surgery: After heart surgery, the ECG machine is used to evaluate the effect of the surgery and monitor the patient's recovery.
Home Healthcare
RN8006 ECG machines are playing an increasingly important role in home healthcare, especially in the context of telemedicine and home health management. Remote monitoring: For patients at risk of heart disease or who have already been diagnosed with heart problems, home ECG machines can provide remote monitoring to help doctors remotely track the patient's heart condition. Early detection: Home ECG machines can help users detect possible heart problems early, such as arrhythmias or myocardial ischemia, so that they can seek medical attention promptly.
Emergency Rescue
RN8006 ECG Machine plays a vital role in the first aid process. They can quickly and accurately examine and treat patients, provide clinicians with objective evidence of the patient's heart status, and quickly identify cardiac emergencies. In addition, the RN8006 ECG Machine needs to quickly and accurately examine and treat patients in first aid, and the lead wires of existing electrocardiographs are prone to intertwining and entanglement, affecting the operation effect and signal transmission, and delaying the rescue time. Therefore, the RN8006 ECG Machine can overcome the problems of easy entanglement of lead wires, small battery capacity, and poor electrode adsorption in the existing technology, and has the advantages of easy use, easy to carry, and strong safety. In the pre-hospital emergency scenario, the electrocardiograph can be used on the 120 ambulance to help emergency personnel quickly complete the ECG examination and transmit the ECG data to the hospital in time, so that the attending doctor can make emergency preparations in advance, thereby improving the efficiency of emergency treatment.
Professional manufacturer
Wuhan Uryn Medical Technology Co., LTD., is a collection of R&D, production, and sales of patient monitor, remoting patient monitor, vital sign monitor, handheld pulse oximeter, electrocardiogram machines. We are also provide SKD and OEM service. we are the main body of the high-tech professional technology company.
Our certificates
Our Cooperative Customers
Frequently asked questions
Q1.Does the ECG Machine RN8003+/RN8006+/RN8012+ support OEM startup LOGO?
A:Yes. The startup LOGO can be customized according to customer needs.
Q2.Does the ECG Machine RN8003+/RN8006+/RN8012+ support multi-languages?
A:Yes.
Q3.Can the ECG Machine RN8003+/RN8006+/RN8012+ customize the suitcase?
A:Yes, we have matching suitcases. We can also customize it for you if necessary.
Q4.Can the ECG Machine RN8003+/RN8006+/RN8012+ use cardiac electrodes?
A:Yes, usually with chest electrode suction balls and limb electrode clips. If you want to use cardiac electrodes, the ECG lead wire needs to be replaced.
Q5.How long the ECG Machine RN8003+/RN8006+/RN8012+ is the warranty period?
A:1 year for host and 6 months for accessories. We can provide extended warranty service, and the supply of accessories is guaranteed for at least 5 years.
