product details
The main functions of the RN100 Handheld Pulse Oximeter include measuring human blood oxygen saturation and pulse rate. The device uses a non-invasive method, that is, the sensor is clamped on the patient's fingertips, and infrared light is used to pass through part of the blood on the fingertips to detect the patient's pulse wave and blood oxygen content. In addition, the functions of the oximeter also include monitoring blood oxygen saturation, evaluating respiratory function, diagnosing and managing sleep disorders, surgery and anesthesia monitoring, exercise and high altitude adaptation assessment, home health monitoring, etc. The oximeter can quickly and accurately measure the indicator of blood oxygen saturation, helping doctors and patients understand the body's oxygen supply status, which is very important for people with underlying diseases or elderly people at home. The oximeter is a device used to measure blood oxygen saturation (SpO2) and heart rate, usually clamped on the finger for measurement.
High-Tech Professional Technology Company That Integrates Research And Development, Production, And Sales Of Monitor Modules And Complete Machines, As Well As Electrocardiographs.
Product advantages
Our advantages
Home medical handheld testing instruments have the advantages of portability, real-time, ease of use, multiple functions, data recording, high cost performance, wide applicability, and battery power supply, and play an important role in monitoring health.
-
Accurate measurement in 0.05% Low perfusion Index, the world leading production in the movement environment.
-
Provide the parameter of PI (Perfusion Index 0.05%-20%).
-
Accurate measurement in all kinds of extreme environment measurement such as neonatal and shock patients.
-
NIBP adopt SAWAA algorithm and SAFD algorithm. SAWAA (Self-Adaptive-Waveform-Amplitude-Adjust) SAFD (Self-Adaptive-Fast-Deflation)
-
Easy operation by 3.5/4-inch color TFT.
-
Multiple vital signs measurement parameters for collocation optional.
RN100S: SpO2
RN100ST: SpO2+Temp
RN100: SpO2+NIBP+TEMP
RN100SE: SpO2+ETCO2
RN100E: SpO2+NIBP+ETCO2
-
Two measurements modes: Spot, Monitoring.
-
Data storage capabilities, support for historical data view and trend chart back. In monitoring mode, can continuously record 48 hours of measurement data. In spot mode, 100 users ID, each user can store 200 sets data.
-
Support audio and visual alarm, support to set alarm upper and lower limit values.
-
Lithium ion battery power supply.
-
Mobile phone APP is Available.
Technology specifications
| Product name |
RN100 |
| CO2 |
Accuracy: ±2mmHg, ±5%mmHg, ±8%mmHg, ±10%mmHg; |
| ETCO2 Range: 0-40mmHg, 41-70mmHg, 71-100mmHg, 101-150mmHg; |
| Oxygen Saturation (%SpO2) |
SpO2:
Measure range:0-100%, 0-240bpm,
Accuracy range:70-100%, 30-240bpm;
Measurement accuracy: ADU(PED) : ±2bpm(70-100%) NEO: ±3bpm On motion condition: ±3bpm;
|
|
PR:
Measure range: 0-254bpm,
Accuracy range: 30-254bpm,
Measurement accuracy: ADU(PED): ±3 bpm NEO: ±3 bpm On motion condition: ±5 bpm;
|
| Temperature |
Measurement range: 25-45℃; |
| Resolution: 0.1℃; |
| Accuracy: 0.1℃; |
| NIBP |
Measurement Range:
Adult: SYS 40 ~ 270mmHg, DIA 10 ~ 210mmHg, MEAN 20 ~ 230mmHg,
PED: SYS 40 ~ 200mmHg, DIA 10 ~ 150mmHg, MEAN 20 ~ 165mmHg,
NEO: SYS 40 ~ 135mmHg, DIA 10 ~ 95mmHg, MEAN 20 ~ 105mmHg;
|
| Independent software protection pressure Adult: 300mmHg, PED:240mmHg, NEO:150mmHg; |
| Independent hardware protection pressure Adult:320-330mmHg, PED:265-275mmHg, NEO:160-165mmHg; |
| Measurement accuracy: ±3mmHg; |
| Pulse Rate (PR) |
Pulse rate range: 40~240bpm; |
| Pulse rate measurement accuracy: <=2% (>=100 BPM) or 2 beats/min (<100 BPM); |
Usage scenario
Hospital
It can monitor the patient's heart rate, rhythm and intensity in real time, and analyze this data in real time to help doctors quickly identify heart abnormalities such as arrhythmias or heart murmurs.
Household Use
The RN100 Handheld Pulse Oximeter can effectively monitor the patient's blood oxygen saturation in home use. Blood oxygen saturation is one of the important indicators for evaluating human health status. It can not only reflect the quality of cardiopulmonary function, but also timely detect potential health risks such as hypoxemia. The use of the Handheld Pulse Oximeter is particularly important for patients with respiratory diseases, cardiovascular diseases, chronic obstructive pulmonary disease, and elderly people who need to stay in bed for a long time.
Outdoors
The RN100 Handheld Pulse Oximeter can be used to detect and monitor sleep apnea symptoms such as sleep apnea disorder (SDB) and sleep apnea. At the same time, for climbers, mountaineers and explorers, the pulse oximeter can be used to monitor oxygen levels in high-altitude environments to avoid altitude-related diseases such as altitude sickness. The RN100 Handheld Pulse Oximeter is very convenient to use outdoors.
Professional manufacturer
Wuhan Uryn Medical Technology Co., LTD., is a collection of R&D, production, and sales of patient monitor, remoting patient monitor, vital sign monitor, handheld pulse oximeter, electrocardiogram machines. We are also provide SKD and OEM service. we are the main body of the high-tech professional technology company.
Our certificates
Our Cooperative Customers
Frequently asked questions
Q1.Does it support OEM startup LOGO?
A:Yes. The startup LOGO can be customized according to customer needs.
Q2.Can it be used for children and newborns?
A:Yes. Accessories for children and newborns are optional.
Q3.How long is the warranty period?
A:1 year for host and 6 months for accessories.
Q4.Does blood pressure need to be calibrated?
A:It has been calibrated before leaving factory and does not need to be calibrated after leaving factor.
Q5.Does it support data export?
A:Data can be exported through USB interface.
